The 5MWh LiFePO4 Liquid Cooling Energy Storage System is a high-capacity, grid-scale energy storage solution designed for industrial solar applications.
Built with advanced liquid cooling technology and safe, long-cycle LiFePO4 battery cells, this system delivers reliable performance, extended lifespan, and superior thermal management for demanding commercial and utility environments.
The 5MWh LiFePO4 Liquid Cooling Energy Storage System is a high-capacity, grid-scale energy storage solution designed for industrial solar applications.
Built with advanced liquid cooling technology and safe, long-cycle LiFePO4 battery cells, this system delivers reliable performance, extended lifespan, and superior thermal management for demanding commercial and utility environments.
| Parameter | Specification |
| Rated Voltage | 1331.2 V |
| Nominal Voltage | 1331.2 V |
| Rated Power | 2.5 MW |
| Nominal Energy | 5.015 MWh |
| Battery Type | LFP 314Ah |
| Protection Level | IP54 / IP55 |
| Communicaiton | RS485/CAN |
| Cooling Type | Liquid Cooling |
| Dimensions | 20FT / 40FT |
| Weight | 40-45T |
| Place of Origin | Anhui China |
| Brand Name | BOX-E/ OEM&ODM |
| Gird | On-gird / Off-gird / Hybrid |
| Inverter Type | Deye/Solis/Megarevo/Other |
| Certification | UN38.3/MSDS/ROHS/Other |
Liquid Cooling System:Maintains optimal battery temperature (±2°C cell consistency), extending cycle life and improving safety under high charge/discharge rates
High Energy Density:5MWh capacity in a standard 20ft/40ft container footprint, maximizing land use efficiency
Modular Design:Scalable from MWh to GWh level, supporting parallel connection for larger projects
IP54 / IP55 Protection:Suitable for outdoor installation in harsh environments
Smart BMS & EMS:Real-time monitoring, remote control, and automatic balancing for optimized performance
Rapid Response: <20ms grid switching for peak shaving and backup power applications
Industrial Solar + Storage:Store excess solar energy during the day for use at night or peak hours, maximizing self-consumption and reducing electricity bills
Peak Shaving:Discharge during high-tariff periods to reduce demand charges and grid reliance
Grid Backup / UPS:Provide emergency power during grid outages for critical industrial loads
Load Leveling:Smooth solar output fluctuations and improve grid stability
EV Charging Integration:Support high-power EV charging stations without straining the local grid
Microgrids & Off-grid:Form a stable power supply with solar and diesel gensets for remote industrial sites
