The All-in-One Cabinet Home Energy Storage System is a pre-integrated solution that combines battery modules, Battery Management System (BMS), Power Conversion System (PCS), thermal management, and safety protection systems into a single unit. Featuring integrated industrial design for plug-and-play operation, it is specifically designed for household and commercial users seeking easy installation, high safety, clean aesthetics, and low maintenance requirements.
The All-in-One Cabinet Home Energy Storage System is a pre-integrated solution that combines battery modules, Battery Management System (BMS), Power Conversion System (PCS), thermal management, and safety protection systems into a single unit. Featuring integrated industrial design for plug-and-play operation, it is specifically designed for household and commercial users seeking easy installation, high safety, clean aesthetics, and low maintenance requirements.
|
DC Battery Parameters |
|
|
Rated Energy (kWh) |
241 |
|
Standard Voltage (V) |
768 |
|
Voltage Range (V) |
672-864 |
|
Battery Type |
LFP |
|
Capacity (Ah) |
314 |
|
Lifespan |
8000 cycles (0.5C, 5% -95% DOD, 80% SOH) |
|
Charge / Discharge Rate (C) |
0.5 |
|
Battery String |
1P48S x 5 |
|
Module Cooling Method |
Liquid Cooling |
|
Inverter Parameters |
|
|
Optional Inverter |
125kW |
|
Power (kW) |
138 |
|
Maximum Current (A) |
200 |
|
Maximum Efficiency |
98.5% |
|
System Parameters |
|
|
Energy Cycle Efficiency |
≥90% |
|
Protection Level |
IP55 |
|
Corrosion Resistance Grade |
C3 is the default option, C4/C5 are optional |
|
Fire Protection System |
Aerosol / Perfluorohexane |
|
Maximum Working Altitude |
3000m (Reduce the rating above 2000m) |
|
Relative Humidity |
0-95% (non condensing) |
|
Working Temperature Range |
-20℃ - +50℃ |
|
Communication method |
4G / CAN / RS485 |
|
Size(Width x Depth x Height) MM |
1155 X 1415 X 2400 |
|
Weight (KG) |
2350 |
|
Warranty |
5 Years |
Pre-Integrated Design: All internal wiring and testing are completed at the factory; on-site, simply connect to PV, grid, and loads for operation.
Simplified Installation: Saves over 60% installation time compared to traditional split systems; deployable by 2 technicians within 4 hours.
Plug-and-Play Interfaces: Standardized waterproof connectors with clear labeling for PV, grid, and load connections to prevent miswiring.
Integrated Protective Structure: IP54-rated enclosure, dustproof and waterproof, suitable for various environments like garages and basements.
Built-In Fire Suppression: Standard equipped with heptafluoropropane or novec 1230 automatic fire extinguishing system with cell-level thermal runaway detection and isolation.
Electrical Safety Design: Complete isolation between DC and AC sides, featuring lightning protection, surge protection, and leakage protection.
Efficient Thermal Management: Intelligent variable-frequency AC/heat pump system ensures stable operation across a wide temperature range of -20°C to 50°C.
Low-Noise Design: Operating noise < 45 dB (measured at 1 meter), suitable for indoor or semi-outdoor installation.
Adaptive Energy Saving: Automatically adjusts cooling power based on load and temperature, with standby power consumption < 20W.
Maintenance-Free Design: Fully sealed structure, no regular cleaning or upkeep required.
Clear Status Overview: 7-inch touchscreen displays real-time operational data with multi-language interface support.
Remote Intelligent Management: Real-time monitoring via mobile app/web portal, supports OTA remote updates and fault diagnosis.
General Households
New Residential Projects
Old Electrical Circuit Retrofits
Aesthetic-Sensitive Spaces
Community Convenience Stores/Small Supermarkets
Small Business Offices
Rural B&Bs & Inns
EV Charging Station Integration
Overseas Market Users
Rental Housing Projects
Emergency & Disaster Relief
Educational Institutions
