Introduction

The energy storage liquid-cooled container is a high-density energy storage solution designed for large-scale new energy power stations, industrial and commercial energy storage, and grid peak shaving and frequency modulation scenarios. It adopts a 20-foot/40-foot standardized container design, integrating battery modules, an intelligent liquid cooling system, a battery management system (BMS), multi-level fire protection devices, and communication interfaces, achieving the core advantages of 'prefabricated production, modular combination, and rapid deployment.'

Introduction

Basic parameters/Size	Unit	20FT	40FT standard container
Match voltage	V DC	Customized
Rated Energy	KWH	Customized
Rated charge & discharge power	KW	Customized
SOC Range	%	5-95
Size	MM	605824382591	1219224382591
Protection level	-	IP5/IP55
Corrosion resistance level	-	C3/C4/C5
Largest weight	KGS	≤38000	≤43000
Temperature control range	℃	-30~+60
Maximum temperature difference per box	℃	≤5
Thermal management methods	-	Industrial-grade liquid cooling unit (cooling + heating + self-circulation mode)
System own power consumption	%	≤5%
Fire protection system	-	Optional battery cluster-level / cabinet-level heptafluoropropane / perfluorohexanone fire suppression
safety monitoring;	-	Thermal runaway detection, smoke detection, temperature detection
communication method;	-	CAN/RS485
detection function	-	Remote monitoring, fault early warning, and strategy optimization

Introduction

Efficient Thermal Management: Using a bionic capillary-style liquid cooling pipe layout, temperature uniformity is improved by 40% compared to traditional air cooling. Temperature differences inside the container are controlled within ≤5℃, effectively reducing the risk of battery thermal runaway and extending cell life by over 20%.
2. High Safety Protection: Equipped with lithium iron phosphate cells (certified by UN38.3 and UL9540A), combined with pack-level perfluorohexanone spray and cabin-level water fire suppression for dual redundancy, along with combustible gas detection and explosion venting devices, creating a five-level safety protection system.
3. High Density and Flexibility: Single-container rated energy covers 3.44MWh–5MWh, with areal energy density reaching 217kWh/m², a 45% improvement over air-cooled systems; supports multi-container parallel “plug-and-play,” suitable for phased deployment in large-scale energy storage stations and mixed-use scenarios with new and old batteries, reducing lifecycle cost (LCOS) by 10%.
4. Intelligent Operation and Maintenance: Through BMS and cloud platforms, cell-level parameter monitoring is achieved, supporting remote management via Web/APP, combined with AI fault diagnosis algorithms for risk prediction. The modular structure reduces single-module maintenance costs by 30% and shortens delivery cycles to within 40 days.
5. Wide Environmental Adaptability: IP54 protection rating + C5 corrosion-resistant design, supports operation in a wide temperature range of -35℃~60℃, adapts to high altitude (≤4000m), high humidity (0~95% non-condensing), and salt fog environments, meeting the requirements for long-term stable outdoor operation.

Introduction

1.New energy support: PV/wind power plant energy storage for peak shaving and smoothing output;
2. Grid-side applications: peak-valley arbitrage, frequency regulation, backup power;
3. Commercial and industrial sector: load shifting, demand management, emergency power supply;
4. Remote areas: off-grid microgrid energy storage systems.
